NONE-POE NVR AI
Features4/8 CH TVI / AHD/CVI 1080P/ 1080P Lite/ 720P/ 720P Lite/WD1 video input4 /8CH DVR supports 2 CH IP video input by default4CH DVR: 4CH analog video input can be switched to 4CH IP video input8CH DVR: 8CH analog video input can be switched to 8CH IP video inputAdopt standard H.265 high profile compression format to get high-qualityvideo at much lower bit rateIntuitive and user-friendly Graphics User Interface (GUI), window styleoperation by mouseMulti-mode recording: manual / timed / motion / AI recordingPlayback: 4 /8CH simultaneously playbackSearch: time slice, time, event, tag searchExpress and flexible backup via USB, network and so onPentaplex: preview, record, playback, backup and remote accessDHCP, DDNS, PPPoE network protocolRemote cont
Този продукт е изчерпан. Можем да Ви уведомим по имейл, когато отново е наличен.
Features
4/8 CH TVI / AHD/CVI 1080P/ 1080P Lite/ 720P/ 720P Lite/WD1 video input
4 /8CH DVR supports 2 CH IP video input by default
4CH DVR: 4CH analog video input can be switched to 4CH IP video input
8CH DVR: 8CH analog video input can be switched to 8CH IP video input
Adopt standard H.265 high profile compression format to get high-quality
video at much lower bit rate
Intuitive and user-friendly Graphics User Interface (GUI), window style
operation by mouse
Multi-mode recording: manual / timed / motion / AI recording
Playback: 4 /8CH simultaneously playback
Search: time slice, time, event, tag search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Remote control via Web or CMS: preview, playback, backup, PTZ and
configuration
Dual stream technology for local storage with high definition, remote
network transmission and remote surveillance with mobile device
Authorization management, log review and device status review
Support 1080P output, true high-resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR Code scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Android OS
Specification
| Model | TD-2004NS-HL-L | TD-2008NS-HL-L | |
| System | OS | Embedded Linux | |
| Video | Analog Video Input | BNC × 4 | BNC × 8 |
| BNC interface (1.0Vp-p; 75Ω) | |||
| TVI/ AHD/CVI: 1080P/ 1080P Lite/ 720P/ 720P Lite/ WD1 | |||
| IP Video Input | 2CH (up to 6CH) | 2CH (up to 10CH) | |
| Up to 2MP@30fps | Up to 5MP@25fps | ||
| Total Input | 6CH | 10CH | |
| Output | HDMI × 1 :1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | ||
| Compression | H.264/H.265 | ||
| Multi-screen Display | 1/4/6/9 | 1/4/6/8/9/13/16 | |
| Audio | Input | RCA ×1 | |
| Output | RCA × 1 (linear, 600Ω) | ||
| Two-way audio | Take up channel one audio input | ||
| Compression | G.711(U/A) | ||
| Record | Resolution | 1080P Lite/ 720P/ WD1 | 1080P Lite/ 720P/ 720P Lite/ WD1 |
| Frame Rate | Analog Channel: 4CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC) 8CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC) (only CH 1 supports) 1080P Lite/720P/WD1: 12fps (PAL)/15fps (NTSC) (other channels support) 720P Lite: 25fps (PAL) / 30fps (NTSC) IP Channel: 25fps (PAL) / 30fps (NTSC) | ||
| Bit Rate | 32Kbps ~ 4Mbps | ||
| Playback | Playback | 4 CH | 8CH |
| Search | Time slice / time / event / tag search | ||
| Smart Search | Highlight colors to display the camera record in a certain period of time, different colors refer to different record events | ||
| Function | Play, pause, FF, FB, digital zoom, etc. | ||
| Alarm | Mode | Manual, motion, exception, smart event | |
| Input | No | ||
| Output | No | ||
| Network | Interface | RJ 45 100Mbps × 1 | |
| Protocol | TCP / IP, HTTP, HTTPS, 802.1x, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, Ipv6, UDP, WebSocket, PPPoE, SNMP, IGMP | ||
| Incoming Bandwidth | 10Mbps | 16Mbps | |
| Outgoing Bandwidth | 30Mbps | 60Mbps | |
| Client Connection | Max. 5 users' access | ||
| Mobile Device | OS | iOS, Android | |
| Storage | HDD | SATA× 1, up to 8TB | |
| Backup | Local Backup | U disk, USB mobile HDD | |
| Network Backup | Yes | ||
| Port | RS 485 | No | |
| USB | USB 2.0 × 2 | ||
| Remote Controller | No | ||
| Others | Power Supply | DC12V / 1.5A | |
| Consumption | ≤ 5W (without HDD) | ||
| Dimensions(mm) | 255 × 222 × 42 (W × D × H) | ||
| Working Environment | -10~50°C, 10%~90% (humidity) | ||
| Certificate | CE, FCC | ||
| Environment Protection | Directive EU RoHS, WEEE, REACH | ||
